NVIDIA MCP7Y50-N002 – NDR 800G OSFP to 4x 200G OSFP Splitter DAC, 2 m

€1.640,00

Taxes included. Shipping calculated at checkout.

Connectivity 800G OSFP to 4x 200G OSFP
Details 2 m passive copper

NVIDIA MCP7Y50-N002 is a genuine 2 m passive copper splitter that breaks one twin-port NDR OSFP cage into four 200G NDR200 OSFP links. It lets a single Quantum-2 switch cage connect four servers, well suited to dense InfiniBand clusters.

Out of stock

Ships across the EU
Secure payment

NVIDIA MCP7Y50-N002 NDR 800G OSFP to 4x 200G OSFP splitter DAC, 2 m

We ship from Belgium to all EU countries. Delivery options, costs and times for your country are shown at checkout.

Brand: NVIDIA

Manufacturer and safety details for this product are available on request.

Highlights

What's inside.

01800G to 4x 200G NDR200One twin-port OSFP cage is split into four 200G links for maximum server density.
02Four servers per cageConnect four ConnectX-7 hosts to one switch cage, reducing switch count in smaller fabrics.
03LSZH jacketLow-smoke zero-halogen jacket for data centres with strict cabling fire-safety rules.
042 m passive copperReaches servers further down the rack from a top-of-rack switch.

In practice

Built for the work.

Use case

Four NDR200 servers from one switch cage

Scale an InfiniBand cluster to more nodes per switch by running four 200G servers from each Quantum-2 cage, ideal where hosts need NDR200 rather than full 400G. At 2 m it reaches servers further down the rack from a top-of-rack switch.

Integration

Quantum-2 QM9700 to 4x ConnectX-7

The twin-port OSFP end fits the NVIDIA Quantum-2 QM9700; the four OSFP ends connect to ConnectX-7 OSFP adapters running NDR200. InfiniBand NDR200, 800 Gbit/s total, 2 m, LSZH. Part 980-9I46G-00N002.

Video

See it in action.

Performance

The numbers, from the source.

Use case: 1-3 m DAC splitters connect a Quantum-2/Spectrum-4 twin-port OSFP switch to two 400G (MCP7Y00) or four 200G (MCP7Y50) ConnectX-7 OSFP adapters. Source: NVIDIA.
